DESCRIPTION

D10 FRONT PANEL
2 3
1 7 8 9 10
D10 INDICATORS OF OPERATION
2
5
If signal lamps 1, 2, 3, and 6 are flashing, it means, that a delay time to
switch off the indicated device is active.

User manual

USER MANUAL
4 5 6 1
1 - burner
1
2 - circulation pump of the direct heating circuit
UWP2
3
- circulation pump for d. h. w. circulation BCP
3 - circulation pump of the mixing heating circuit
UWP
- circulation pump for d. h. w. circulation BCP
4
4 - opening of the mixing valve (M+)
5 - closing of the mixing valve (M-)
6 - circulation pump for d. h. w. warming BLP
6
1 - fastening screws
2 - LCD display
3 - setting the steepness of the
heating curve (DC*
4 - setting the minimum temperature
of liquid fuel boiler
5 - info / Esc key
6 - navigation button
7 - setting of required day temperature
8 - setting of required night temperature
9 - switch for selecting the operation
mode
10 - setting of d. h. w. temperature
* **MC - mixing heating circuit
**DC - direct heating circuit
8
or MC** )
