SERVICE PARAMETER TABLES WITH DESCRIPTION

BASIC PARAMETERS > S1.x
Parameter Parameter description
HYDRAULIC SCHEME SELECTION
S1.1
TEMPERATURE SENSOR ELEMENT TYPE
S1.2
0 - Pt-1000; 1 - KTY
INPUT (C.17)
S1.3
0 - RF (room temperature sensor)
1 - RLF (mixing circuit return- pipe temperature sensor)
2 - RLKF (boiler return- pipe temperature sensor)
3 - EF (floor temperature sensor)
4 - BF3 (d. h. w. flow indicator)
5 - BF3 (flow switch for d. h. w. warming)
6 - AGF (exhaust gas temperature sensor)
7 - BF3 (room temperature by d. h. w. warming with heat pump)
DIGITAL INPUTS C.12 AND C.17
S1.4.
1 - remote activation of room heating on input C.12
2 - remote activation of d. h. w. warming on input C.12
3 - remote activation of room heating and d. h. w. warming on input C.12
4 - remote activation of room heating on input C.17
5 - remote activation of d. h. w. warming on input C.17
6 - remote activation of room heating and d. h. w. warming on input C.17
7 - additional direct heating circuit, with delayed boiler switch ON - on input C.12
8 - additional direct heating circuit, without delayed boiler switch ON - on input C.12
9 - additional direct heating circuit, with delayed boiler switch ON - on input C.17
10 - additional direct heating circuit, without delayed boiler switch ON - on input C.17
11 - switch to cooling mode
Input is activated, if input and GND are connected.
ROOM SENSOR RF INFLUENCE
0 - no influence (temperature display only)
1 - influence on mixing heating circuit (MC)
2 - influence on direct heating circuit (DC)
3 - influence on both heating circuits (MC and DC)
ROOM SENSOR DD2 INFLUENCE
S1.6
0 - no influence (temperature display only)
1 - influence on mixing heating circuit (MC)
2 - influence on direct heating circuit (DC)
3 - influence on both heating circuits (MC and DC)
OPERATION MODE BY SWITCH POSITION
S1.7
1 - operation on night temperature mode
2 - cooling mode
Service settings manual
Setting span
401 ÷ 422d
0 ÷ 1
0 ÷ 7
1 ÷ 11
0 ÷ 3
0 ÷ 3
1 ÷ 2
40
Units Default
setting
- 401
-
0
- 0
- 1
-
3
-
3
- 1
