This controller uses a mains voltage of 230 V ~, 50 Hz. All mains connections are in con-
nector A and all low voltage connections are in connector C (temperature sensors).
Con- Con- Contact
nector tact marking
no.
A 1 B1
A 2 LB1
A 3
A 4 UWP2 /
BCP
A 5
A 6 M+
A 7 BLP
A 8 UWP /
BCP
A 9 L (R)
C 10 COM2/
FS1
C 11 COM/
FS2
C 12 BF2 /
SF /
KF2
C 13 BF1
C 14 VF
C 15 KF
C 16 AF
C 17 RF /
RLF /
KTF
C 18 GND
Installation manual
Description
- potential free contact output for burner control
- potential free contact output for burner control
N - mains (neutrall wire)
- direct heating circuit circulation pump UWP2
- d. h. w. circulation pump BCP
- solar collector circulation pump KTP
- switchover between two heat sources or loading pump
M- - closing of the mixing valve
- switching into position for d. h. w. warming
- opening of the mixing valve
- switching into position for direct heating circuit
- d. h. w. warming pump BLP
- electric heater for d. h. w.
- mixing circuit circulation pump UWP
- d. h. w. circulation pump BCP
- circulation pump KTP for sun collectors
- mains (phase wire)
- BUS connection to other (slave) controllers
- day temperature of analogue room unit FS10-11
- communication with digital room unit DD2
- night temperature of analogue room unit FS10-11
- the second sensor of storage tank temperature BF2
- heat accumulator temperature sensor SF
- solid fuel boiler temperature sensor KF2
- remote activation
- sensor of storage tank temperature BF1
- sensor of mixing circuit stand-pipe temperature VF
- liquid fuel boiler temperature sensor KF
- outdoor temperature sensor AF
- room temperature sensor RF
- return-pipe of mixing circuit RLF, return-pipe
boiler RLKF, floor temperature sensor EF, circulation BF3, exhaust
gas AGF temperature sensor, room temperature sensor BF3*
- sun collectors temperature sensor KTF
* refer to parameter S1.3
- common contact, signal ground
