Solarbayer PROMATIC D10 Bedienungsanleitung Seite 68

MARKING OF TEMPERATURE SENSORS
Sensor Name
D. h. w. storage tank temperature sensor
Heat accumulator temperature sensor
Solid fuel boiler temperature sensor
D. h. w. storage tank temperature sensor
Stand-pipe temperature sensor
Liquid fuel boiler temperature sensor
Outdoor temperature sensor
Room temperature sensor
Return pipe temperature sensor
Boiler return-pipe temperature sensor
Floor temperature sensor
D. h. w. circulation temperature sensor
Exhaust gas temperature sensor
Sun collectors temperature sensor
TABLE: Temperature sensors resistance TYPE/Pt (Pt-1000)
Temperature Resistance
[°C]
[Ω]
-20 922
-15 941
-10 961
-5 980
0 1000
5 1020
10 1039
15 1058
20 1078
25 1097
30 1117
Installation manual
Temperature Resistance
[°C]
[Ω]
35 1136
40 1155
45 1175
50 1194
55 1213
60 1232
65 1252
70 1271
75 1290
80 1309
85 1328
Connector
(sensor mark)
Symbol
C.12 (BF2)
C.12 (SF)
C.12 (KF2)
C.13 (BF1)
C.14 (VF)
C.15 (KF)
C.16 (AF)
C.17 (RF)
C.17 (RLF)
C.17 (RLKF)
C.17 (EF)
C.17 (BF3)
C.17 (AGF)
C.17 (KTF)
Temperature Resistance
[°C]
[Ω]
90 1347
95 1366
100 1385
105 1404
110 1423
115 1442
120 1461
125 1480
130 1498
135 1415
140 1536
68
Sensor Type
Pt1000
TF/Pt
TF/Pt
TF/Pt
TF/Pt
VF/Pt
TF/Pt
AF/Pt
PS10/Pt OR FS10/Pt
VF/Pt
VF/Pt
TF/Pt
VF/PT
CF/Pt
TF/Pt
Temperature Resistance
[°C]
[Ω]
145 1555
150 1573
155 1592
160 1611
165 1629
170 1648
175 1666
180 1685
185 1703
190 1722
195 1740
