Symbols for heating circuits
Mixing heating circuit - MC.
Direct heating circuit - DC.
D. h. w. warming.
D. h. w. circulation.
Time programs
Time programs for room heating P1 and P2.
Time program for d. h. w. warming.
Time program for d. h. w. circulation.
Time program for anti-legionella function.
Symbols for operation mode indication
Switch off.
Heating turned on - automatic mode.
Cooling turned on - automatic mode.
Day temperature heating operation mode.
Night temperature heating operation mode.
Manual operation.
D. h. w. warming or circulation - permanent switch on.
D. h. w. warming circulation - permanent switch off.
Operation according to program timer - day temperature.
Operation according to program timer - night temperature.
11 User manual
