Selection option
1)
External MANUAL
2)
External key lock
Overflow monitoring
1)
Function: See the "Settings menu – Manual operation" section.
2)
Function: see "Key lock ON" section.
Table 20: Function control input DI1 or DI2
Override function priorities
Priority* Function
1 OFF, External OFF (binary input), External OFF (bus system)
2 MAX, External MAX (binary input), External MAX (bus system)
3 MIN, External MIN (binary input), External MIN (bus system)
4 MANUAL, External MANUAL (binary input)
Table 21: Override function priorities
* Priority 1 = highest priority
Key lock priorities
Priority* Function
1 Key lock: digital input active
2 Key lock active via menu and buttons
3 Key lock: not active
Table 22: Key lock priorities
* Priority 1 = highest priority
The analogue inputs are preassigned at the factory and preset to sensor input PT1000. To
ensure correct, higher-level system control, the customer must not make any modifica-
tions.
Wilo Net is a bus system which enables up to 21 Wilo products (participants) to communic-
ate with one another. The Wilo-Smart Gateway is one of these participants.
Application for:
• Remote access via Wilo-Smart Gateway
• Remote control
Bus topology:
The bus topology consists of several participants connected in series. The participants are
connected via a shared communication cable.
The bus must be terminated at both ends of the communication cable. This is done in the
settings menu for the two external participants. All other subscribers should not have ac-
tivated termination.
All bus subscribers must be assigned an individual address (Wilo Net ID).
This address is set in the system's settings menu.
To terminate:
In the "Settings" menu , select
1. "External interfaces"
2. "Wilo Net setting"
Function control input DI1 or DI2
Contact open: System is running in the mode set on
the system or in the mode requested via bus com-
munication.
Contact closed: System is set to MANUAL.
Contact open: Key lock is deactivated.
Contact closed: Key lock is activated.
Contact closed: System is running in the mode set
on the system.
Contact open: Overflow detected. The system issues
a warning. The system will not flush for the duration
of the warning.
