Variable
ModBus/TCP-Datenadresse
EtherNet/IP-Assembly Instance
Datengesamtlänge an PF
Datengesamtlänge von PF
Feldbus-Anschlüsse
Das Modul nutzt den standardmäßigen Ethernet-Anschluss RJ45. Das Modul nutzt verdrillte Kabel.
Externe Abschlüsse sind nicht erforderlich.
RJ45 (Standard)
Stift Signal
1
TD+
2
TD-
3
RD+
4
Abschluss
5
Abschluss
6
RD-
7
Abschluss
8
Abschluss
9836 2105 04
Grenzwerte
000h + I (I = 0, 1, ...) Von PF
400h + I (I = 0, 1, ...) An PF
Die Datenlänge in PF ist auf 122 Byte
beschränkt. Per ModBus/TCP- und
EtherNet/IP-Standard sind 1024 Byte
Daten erlaubt.
0000h + I (I = 0, 1, ...) Von PF
4000h + I (I = 0, 1, ...) An PF
Die Datenlänge in PF ist auf 122 Byte
beschränkt. Per ModBus/TCP- und
EtherNet/IP-Standard sind 1024 Byte
Daten erlaubt.
Eingang 100, Ausgang 150,
Konfiguration 5 und Größe = 0
0-122 Byte
Die Datenlänge in PF ist auf 122 Byte
beschränkt. Per ModBus/TCP- und
EtherNet/IP-Standard sind 1024 Byte
Daten erlaubt.
0-122 Byte
Die Datenlänge in PF ist auf 122 Byte
beschränkt. Per ModBus/TCP- und
EtherNet/IP-Standard sind 1024 Byte
Daten erlaubt.
Feldbus-Konfiguration, Anhang
Informationen
Diese Adresse ist wortbasiert.
Diese Adresse ist bitbasiert.
Wird zur Konfiguration eines
Ethernet/IP-Moduls verwendet.
Wert muss für PF und SPS
übereinstimmen
Wert muss für PF und SPS
übereinstimmen
