Operation
Drain distillate
End of process
➜
Confirm or discard all changes with
Process parameters
Process parameters
➜
Tap the
–
The process parameters menu opens.
➜
Touch the function button of the desired parameter and adjust the value using the
screen keyboard, see also "User input" on page 104.
Parameters
Heating tape
Heating tape
automatic
Evacuation after
draining the
collector
Educt empty:
additional evap-
oration time
Forced draining
of the collector
Standby timer
after educt
container runs
empty
➜
➜
➜
Distillate draining time
▪ In the selection field, define a distillate draining time
(adjustment via plus/minus buttons or tap/on-screen
keyboard).
Specify here whether the distillate and/or residue are
drained at the end of the process. Touch the corresponding
checkbox to activate (checkmark) or deactivate the
selection.
Accept
button in the footer.
Function
Performance of the heating tape during operation.
Range: 10 – 100% in increments of ten.
(see "Heating tape (optional)" on page 96)
Automatically switch on heating tape yes/no.
Range: on / off.
Evacuation period of the bypass line after draining the
collector vessel.
Range: 1 – 9999 s.
When the educt container runs empty: Additional evapo-
ration time for evaporation of the remaining educt in the
evaporation flask.
Range: 1 – 9999 s.
Forced draining of the collector active: Collector will be
drained after 1 – 9999 seconds, regardless of the filling
level.
Range: 1 – 9999 s.
Activate/deactivate forced draining of the collector (deter-
mines previous parameter!).
Range: active / inactive
Time until the standby mode is activated after the educt
container runs empty.
Range: 1 – 9999 s.
Hei-VAP parameters
page 133.
Data logging
, see section "Data recording" on page 118.
Save
, see section "Recipes" on page 134.
Cancel
or
.
, see section "Parameters Hei-VAP" on
140
