10.4 8x output modules, RMV04-8DO_M8 and
RMV04-8DO_M12
Electrics
Outputs DIN EN 61131-2
Output voltage
Output current
Overload protection
Line length for M8 and M12 connection
Power supply
U and U
Q1 Q2

11 Spare parts and accessories

Spare part
Bus coupler with fieldbus protocol EtherNet/
IP™
(incl. 2x tie rods,1x seal and 1x manual)
Accessories
M12x1 protective cap
End plate for bus coupler
(incl. 2x mounting screws and 1x seal)

11.1 8x input/output module, 8DI/8DO

Delivery incl. 2x tie rods and 1x seal
8x input module (8x M8)
8x input module (4x M12)
8x output module (8x M8)
8x output module (4x M12)
Accessories
Straight plug connector, with self-clinching
screw, M8x1, 3-pin
M8x1 protective cap for inputs (delivery unit = 25 pieces)
M12x1 protective cap for inputs (delivery unit = 25 pieces)
M12 Y-distributor with M12 self-clinching screw,
5-pin, 2x M12 cable socket, 1x M12 cable plug

11.2 Power plug for bus coupler and output module

Plug connector for power supply,
Socket, M12x1, 4-pin
for cable Ø 4-8 mm, A-coded
Plug connector for input/output modules

12 Disposal

Dispose of the device in accordance with the currently applicable regulations in
your country.
AVENTICS™ EtherNet/IP™ | R412012728-BAL-001-AD | English
8 digital outputs
Nominal value 24 V
H signal voltage drop ≤ 1.5 V
Nominal value 0.5 A
For thermal reasons, the outputs may not be
loaded with anything above the nominal cur-
rent for long periods.
Switches off at 0.6 to 1.2 A
Autom. start-up when load is reduced
Max. 30 m
Nominal value 24 V
(+20 %/-15 %)
Order number
R412012755
Order number
R419800769
R412003490
Order number
Order code
8DI_M8 R412003489
8DI_M12 R412008040
8DO_M8 R412005968
8DO_M12 R412005968
Cable Length Order number
2m 894 620 360 2
5m 894 620 361 2
10m 894 620 362 2
R412003493
182 331 200 1
894 100 239 2
Order number
o
180 (X10, POWER) 894 105 432 4
o
90 (X10, POWER) 894 105 442 4
M12x1 plug, straight 1 834 484 222
M12x1 plug, angled 1 834 484 223
M12x1 dual plug for 1 834 484 246
cable Ø 3 mm or
5 mm
30
