Technische Daten
110
• JIS B2220
– 10K (DN 50...300 / 2...12")
– 20K (DN 15...40 / ½...1½")
Promag H
Der zulässige Nenndruck ist abhängig vom Prozessanschluss, der Dichtung und Nennweite.
Details finden Sie in der separaten Dokumentation "Technische Information" →  130.
Promag L
• EN 1092-1 (DIN 2501)
– PN 6 (DN 350...2400 / 14...90")
– PN 10 (DN 200...2400 / 8...90")
– PN 16 (DN 25...2000 / 1...78")
• EN 1092-1, loser Blechflansch
– PN 10 (DN 25...300 / 1...12")
• ASME B16.5
– Class 150 (1...24")
• AWWA C207
– Class D (28...90")
• AS2129
– Table E (DN 350...1200 / 14...48")
• AS4087
– PN 16 (DN 350...1200 / 14...48")
Promag P
• EN 1092-1 (DIN 2501)
– PN 10 (DN 200...600 / 8...24")
– PN 16 (DN 65...600 / 3...24")
– PN 25 (DN 200...600 / 8...24")
– PN 40 (DN 25...150 / 1...6")
• ASME B 16.5
– Class 150 (1...24")
– Class 300 (1...6")
• JIS B2220
– 10K (DN 50...600 / 2...24")
– 20K (DN 25...600 / 1...24")
• AS 2129
– Table E (DN 25 / 1", 50 / 2")
• AS 4087
– PN 16 (DN 50 / 2")
Promag W
• EN 1092-1 (DIN 2501)
– PN 6 (DN 350...2000 / 14...84")
– PN 10 (DN 200...2000 / 8...84")
– PN 16 (DN 65...2000 / 3...84")
– PN 25 (DN 200...1000 / 8...40")
– PN 40 (DN 25...150 / 1...6")
• ASME B 16.5
– Class 150 (1...24")
– Class 300 (1...6")
• AWWA
– Class D (28...78")
• JIS B2220
– 10K (DN 50...750 / 2...30")
– 20K (DN 25...600 / 1...24")
Promag 50
