SICK TDR Betriebsanleitung Seite 91

LFP Cubic
Parameter
AutCal
Q1MENU, Q2MENU,
Q3MENU, Q4MENU
SPx
RPx
FHx
FLx
OUx
SimQx
TYP2/3/4
QAMENU
QAHIGH
QALOW
QAPOL
QATYP
8014825/YE12/2014-09-15 © SICK AG • Level sensors • Germany • Subject to change without notice
6 Menu overview
Description
See Chapter 2 "Commissioning the LFP"
See Chapter 3 "Configuring the switching outputs"
Switching point, switching output 1 or 2 or 3 or 4 (SPx > RPx)
Note: Not displayed if the switching output in the OUx menu is
set to error or window.
Reset switching point, switching output 1 or 2 or 3 or 4
Note: Not displayed if the switching output in the OU2/3/4 menu is set to error
or window.
Upper threshold (high) window function, switching output 2/3/4 (FHx > FLx)
●
Lower threshold (low) window function, switching output 2/3/4
●
Note: Not displayed if the switching output in the OU2/3/4 menu is set to error
or hysteresis.
Switching function, switching output
Qx-Hno = Hysteresis function, normally open
●
Qx-Hnc = Hysteresis function, normally closed
●
Qx-Fno = Window function, normally open (function only available for Q2/3/4)
●
Qx-Fnc = Window function, normally closed (function only available for
●
Q2/3/4)
Qx-Eno = Error signal, normally open (function only available for Q2/3/4)
●
Qx-Enc = Error signal, normally closed (function only available for Q2/3/4)
●
If Qx is used as an error signal, SPx/FHx and RPx/FLx are hidden in the menu.
See Chapter 5.3 "Testing the configuration"
Qx-PNP = Switching output in PNP circuit
●
Qx-NPN = Switching output in NPN circuit
●
Qx-Drv = Switching output executed in push/pull function
●
See Chapter 4 "Configuring the analog output"
Input of the fill level in mm for 20 mA/10 V signal (QAHIGH > QALOW)
Input of the fill level in mm for 4 mA/0 V signal
The analog output signal can be inverted
QA-Nrm = Analog output signal as configured
●
QA-INV = Analog output signal is inverted: QAHIGH 4 mA/0 V and QALOW 20
●
mA/10 V
Setting of the output signal
4-20 mA
●
0-10 V
●
Auto V = Qa operated with voltage output of 0 to 10 V
●
Auto A = Qa operated with current output of 4 to 20 mA
●
Auto? = Automatic signal detection based on the existing load
●
During a menu query, either 4-20 mA or 0-10 V is displayed.
