LFP Cubic
Index Name
(decimal)
126 System
monitor
127 Display text
128 Simulate
measured
value
129 Level
8014825/YE12/2014-09-15 © SICK AG • Level sensors • Germany • Subject to change without notice
8 IO-Link
Format Access
16-bit R
record
8 x 8 bit R
8-bit R/W
unsigned
16-bit R/W
unsigned
Value
Record System diagnosis flags
Bit 0 Internal warning
Bit 1 Q1 short-circuit
Bit 2 Q2 short-circuit
Bit 3 QA overload
Bit 4 QA current cannot be set or
excess temperature
Bit 5 Supply voltage for IO-Link insuf-
ficient
Bit 6 Supply voltage for Q1 and Q2
insufficient
Bit 7 Supply voltage for QA insufficient
Bit 8 Temperature of the electronics
too high
Bit 9 Temperature of the display too
high
Bit 10 Measurement poor or conspicu-
ous (warning)
Bit 11 Measurement not possible
Bit 12 Echo curve invalid (measure-
ment not possible)
Bit 13 Device not adapted to the tank
(AutCal still has to be called up)
Bit 14 Other (unknown) error
Bit 15 Reserved (= 0)
String Current display on the screen,
e.g., 0 mm or 0%
0 Normal This parameter is volatile.
measuring This means that the normal
operation measuring operation will always
be started again after the LFP
1 Simulation is reset.
operation
Read
Current level in millimeters
Write
If simulate measured level is set
to 1, the measured level can be
simulated by writing.
