Siemens SIMOVERT MASTERDRIVES Betriebsanleitung Seite 85

10.2004
484
<1>
<2>
M8
ground
terminal
50 380
480
6SE7031-6ES87-2DC0: M12
<1>
6SE7031-3FS87-2DC0: M20
<2>
6SE7031-6ES87-2DC0: M40
6SE7031-3FS87-2DC0: M32
Siemens AG 6SE7087-6CX87-2DA1
SIMOVERT MASTERDRIVES
50
Braking resistor for
100 kW; 4 Ω
100 kW; 6.2 Ω
Fig. 7-5 Mounting diagram, braking resistor
Braking Unit
736
710
Type
6SE7031-6ES87-2DC0
6SE7031-3FS87-2DC0
Technical Data
2 M8 pin terminals
710
736
∅ 9
Weight, approx.
45 kg
45 kg
7-7
