Siemens SIMOVERT MASTERDRIVES Betriebsanleitung Seite 81

10.2004
Cabinet - roof mounting
A
15
Wall mounting (electrical connection to the left)
Airflow
(convection)
Siemens AG 6SE7087-6CX87-2DA1
SIMOVERT MASTERDRIVES
525
540
Braking resistor for
5 kW; 20 Ω
5 kW; 80 Ω
5 kW; 124 Ω
Fig. 7-1 Mounting diagram, braking resistor
Braking Unit
∅ 5.5 x 8
Mulit-element resistor MF2
Type
6SE7021-6CS87-2DC0
6SE7018-0ES87-2DC0
6SE7016-4FS87-2DC0
Technical Data
A
PE
150
180
7-3
