3.2 Adaptor plate installation of the 5 – 50 kW braking units
7
Siemens AG 6SE7087-6CX87-2DA1
SIMOVERT MASTERDRIVES
Adapter plate
G-type
mounting rail
EN 50035
Adapter plate order number: 6SX7010-0KC01
Fig. 3-5
Braking Unit
263
Braking Unit
Shield plate
G-type
mounting rai
Adapter plate
Hexagon nut M6
Mounting, Connecting-Up
3-5
