Floor mounting
A
View
M20
M25
M6
ground
terminal
A
View
Wall mounting
Siemens AG 6SE7087-6CX87-2DA1
SIMOVERT MASTERDRIVES
T1/T2 pillar
terminal
2.5 mm
2 M6 pin
terminals
400
430
400
Braking resistor for
20 kW; 20 Ω
20 kW; 5 Ω
Fig. 7-3 Mounting diagram, braking resistor for floor and wall mounting
Braking Unit
2
∅ 9
The minimum clearance to other
components must be 100 mm on all sides
with ventilation slots!
Type
6SE7023-2ES87-2DC0
6SE7026-3CS87-2DC0
Technical Data
430
400
∅ 9
Weight, approx.
17 kg
15 kg
