Device menu
Configuration
point
Ch. X source temp.
Ch. X Source Temp.
417102279 Version 1-09.2019
Selection / option
Analogue inputs /
* IN4 temperature input 1
* IN5 temperature input 2
......IN11 Universal input. 2
uncomp.
* IN11 Universal input. 2 comp.
IN12 Universal input 3 uncomp.
* IN12 Universal input. 3 comp.
* = Please select only the highlighted points
2-wires
3-wires
36
Explanation
Determining the source for
the temperature display
and for the temperature
compensation of the
respective channel.
Select this option to use
the temperature signal of
another channel for the
display and temperature
compensation of this
channel.
Selecting the temperature
sensor connection type
Default
Channel 1: IN4
Channel 2: IN5Channel
3: IN11 comp.
Channel 4: IN12 comp.
3-wires
