ATTENTION!
Hold the tool fixture tight when you detach it. The tool
fixture is pressed out of the spindle.
ATTENTION!
The tool clamping system must not be activated when
the machine is operated.
Img.4-12: Extraction tool
ATTENTION!
When using an optional MT4 spindle.
When installing a cold morse taper into a heated-up machine those MT seats tend to
shrink on the morse taper contrary to the quick-releaser tapers.
