Installation; Field Of Use; Limits Of Use; Machine Outfit - Frigomat Kikka 3P-Serie Gebrauchsanweisung Und Wartungshandbuch

3. INSTALLTION

3.1 FIELD OF USE

The KIKKA machines is expressly designed and engineered for the production og soft ice
cream and frozen yogurt.

3.2 LIMITS OF USE

Never use the machine with variable supply voltage and/or more than +/- 10% of the value
showed in the nameplate or when the feeder is damaged;
Do not use the machine for purposes different from the ones indicated in the present
manual;
Do not use the machine in explosive environment;
Do not wash the machine with high-pressure jets of water or harmful substances;
Do not expose the machine to excessive heat or humidity;
Do not use completely unbalanced mixtures and/or quantities not in compliance with the
specifications reported on the packing.

3.3 MACHINE OUTFIT

- No. 2 cleaning rods
- Soft paddle
- Beater staffing box
- Gasket extractor
- OR kit
- Fuse kit

3.4 COMMISSIONING

Bring the machine to the place of employment and check that everything is all right as far
as installation concerns:
Power supply;
Water supply (only in case of water condensing);
Suitable run-off pit for water (only in case of water condensing).
Lock the machine by means of the apposite lever located on the front wheels;
Place the machine far from walls or other obstacles (at least 10 cm sideways and 30 on
the back). In case the machine is provided with water-cooled condenser, the distance
between the wall and the back panel can be reduced to 10 cm.
Make sure that the supply voltage and power comply with the values reported on the
rating plate placed on the back panel;
Connect the machine to the mains; upstream the machine, arrange an omnipolar
master switch with minimum contact opening equal to 3 mm and adequate power,
interlocked with fuses to allow plugging and unplugging at open circuit.
Connect the feeder to a type-approved plug: the feeder shall be well stretched, to avoid
rolling and overlapping. It shall not be exposed to possible shocks or tampering
attempts and far from liquids, water and heat sources. It shall not be damaged,
otherwise make it be replaced by qualified personnel with another section and type
7 - ENGLISH
- Feeding needle (for gravity models
only)
- FRIGOMAT lubricant
- Manual of use and maintenance
- Declaration of conformity
- Certificate of guarantee
