Knee lever brake
(brake activated by pressure):
Knee lever brakes are used in addition to
the parking brake (drum brakes)� When or-
dered, they will be assembled and adjusted
at the factory� In case the braking action is
reduced by distance-alteration (wheel-knee
lever brake), this can be regulated by adjust-
ing the sliding nut in the C-rail�
5.

Technical Data

5.1 Overall dimensions of SIMPLY LIGHT
Maximum length
Overall width
Height to upper edge
of adaptor plate
Minimum handle height
(90° seat angle,
90° handle)
Maximum handle height
(90° seat angle,
90° handle)
Weight (basic version without seat unit) 20 - 23 kg, depending on the version
5.2 Tyre pressure table
Front swivel wheels
Rear wheels 12˝
Rear wheels 16˝
Rear wheels 22˝
Rear wheels 24˝
Important: The maximum load for SIMPLY LIGHT is 80 kg (incl� weight of user
and seat shell incl� options)�
SIMPLY LIGHT (22˝/24˝)
Seat width 35 / 40 / 45 cm
83 cm
57 / 62 / 67 cm
50,5 cm
95 cm
105 cm
Tyre pressure (bar) maximum
25
25
30
40
40
3
SIMPLY LIGHT (12˝/16˝)
Seat width 35 / 40 / 45 cm
83 cm
57 / 62 / 67 cm
50,5 cm
95 cm
105 cm
TECHNICAL DATA
