Siemens simovert masterdrives Betriebsanleitung Seite 293

05.2006
Designation
Order number 6SE70...
Rated voltage [V]
Input
Output
Rated frequency [Hz]
Input
Output
Rated current [A]
Input
Output
DC link voltage [V]
Rated output [kVA]
Aux. power supply [V]
Pulse frequency [kHz]
Derating curve
Load class II acc. to EN60146-1-1:
Base load current
Overload current
Cycle time
Overload duration
Losses, cooling, power factor
Power factor
Line cosϕ1N
Converter cosϕU
Efficiency η
Pulse frequency 5 kHz
Dissipated losses [kW]
Pulse frequency 5 kHz
Cooling air required [m³/s]
Sound pressure level, dimensions, weights
Sound pressure level [dB(A)]
Type of construction
Width
Height [mm]
Depth
Weight [kg]
*) With Z = F02; 2.5 kHz pulse frequency
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES
31-0EE 0 31-2EF 0 31-8EF 0
3 AC 380 to 480 (-15 % / +10 %)
3 AC 0 ... rated input voltage x 0.86
50/60 ± 6 %
0 ... 400
101 136
92 124
510 ... 650
61...76 82...103 102...128
DC 24 (20 -30) (3.0 A without options; more with options)
5.0 – 10.0 5.0 – 10.0 5.0 – 9.0
5.0 – 6.0 *)
0.91 x rated output current
1.6 x rated output current
> 0.98 > 0.98 > 0.98
< 0.92 ind. < 0.92 ind. < 0.92 ind.
0.97 0.97
1.38 1.83
0.10 0.14
69 69
E F
270 360
1050 1050
350 350
55 65
= 5 corresponds to MASTERDRIVES Motion Control
= 7 corresponds to MASTERDRIVES Motion Control Performance 2
Operating Instructions
Value
32-1EG 0 32-6EG 0
171 192 238
155 175 218
186 *) 210 *) 260 *)
115...145 143...181
5.0 – 7.5 5.0 – 7.5
300 s
30 s
> 0.98 > 0.98
< 0.92 ind. < 0.92 ind.
0.97 0.98 0.98
2.43 2.77 3.45
0.14 0.31 0.31
69 80
F G
360 508 508
1050 1450 1450
350 350 460
65 155 155
Technical Data
80
G
11-5
