Torque motors
1FW3
Input in
P099
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 to 30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES
Motor order Speed
number (MPRD) n [rpm]
n
1FW3201-1.H 300
1FW3202-1.H 300
1FW3203-1.H 300
1FW3204-1.H 300
1FW3206-1.H 300
1FW3208-1.H 300
1FW3AH150 gen. General template for customer-specific
1FW3
1FW3AH200 gen. General template for customer-specific
1FW3
1FW3AH280 gen. General template for customer-specific
1FW3
1FW3281-1.G 250
1FW3283-1.G 250
1FW3285-1.G 250
1FW3288-1.G 250
1FW3281-1.E 150
1FW3283-1.E 150
1FW3285-1.E 150
1FW3288-1.E 150
for future applications
1FW3150-1.H 300
1FW3150-1.L 500
1FW3150-1.P 800
1FW3152-1.H 300
1FW3152-1.L 500
1FW3152-1.P 800
1FW3154-1.H 300
1FW3154-1.L 500
1FW3154-1.P 800
1FW3155-1.H 300
1FW3155-1.L 500
1FW3155-1.P 800
1FW3156-1.H 300
1FW3156-1.L 500
1FW3156-1.P 800
Operating Instructions
Parameterization
Torque Current Number
M [Nm] I [A] of pole
n n
300 22
500 37
750 59
1000 74
1500 117
2000 152
2400 153
3400 222
4800 306
6700 435
2500 108
3500 150
5000 207
7000 292
100 7
100 11
100 17
200 14
200 22
200 32
300 20
300 32
300 47
400 28
400 43
400 64
500 34
500 53
500 76
pairs
14
14
14
14
14
14
7
14
17
17
17
17
17
17
17
17
17
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
8-47
