05.2006
Type K: The 5-pole terminal strip is used for connecting up a 24 V voltage
supply and a main or bypass contactor.
X9 - external
DC 24 V supply,
The connection base is easily accessibly located on the DIN rail below
main contactor
the slide-in unit of the electronics box.
control
The voltage supply is required if the inverter is connected up via a main
or bypass contactor.
The connections for the contactor control are floating.
5
4
3
2
1
Connectable cross-section: 2.5 mm² (AWG 12)
Table 7-4
NOTE The excitation coil of the main contactor has to be damped with
overvoltage limiters, e.g. RC element.
The 230 V fan has to be supplied with AC230 V externally. The
connecting points are located on the fuse-disconnectors on the right
next to the DIN rail of X9.
WARNING
The external 24 V voltage supply has to meet the requirements of safe
electrical isolation (PELV current circuit = Protective Extra Low
Voltage).
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES
Terminal Designation
5 Main contactor control
4 Main contactor control
3 n.c.
2 0 V
1 +24 V (in)
Connection of external DC 24 V aux. voltage supply and main contactor
control (Type K)
Operating Instructions
Meaning
Main contactor control
Main contactor control
Not connected
Reference potential
24 V voltage supply For current
requirement
see section
Connecting-up
Range
AC 230 V
1 kVA
0 V
"Technical
Data"
7-9
