05.2006
X103 - 10 V voltage The following connections are provided on the control terminal strip:
output, SCom1,
♦ 10 V aux. voltage (max. 5 mA) for the supply of external
SCom2
♦ 2 serial interfaces SCom1 and SCom2 (USS / RS485)
Connectable cross-section: 0.14 mm
The terminals 23 and 24 are short-circuit proof.
Terminal 23 is at the top when installed.
Table 7-6
Either an OP1S or a PC can be connected up via the 9-pole SUB D
X300 - Serial
interface socket.
The 9-pole SUB D socket is internally coupled with the USS bus, with
the result that it is possible to exchange data with further converters
and inverters which are linked via the USS bus.
1
5
9 6
Table 7-7
Switch settings
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES
potentiometers
Terminal Designation
23 P10 V
24 N10 V
25 RS485 P (SCom2) USS bus connection SCom2
26 RS485 N (SCom2) USS bus connection SCom2
27 RS485 P (Scom1)
28 RS485 N (Scom1)
Control terminal strip X103
Pin Name
1 n.c.
2 RS232 RxD Receive data via RS232
3 RS485 P
4 Boot Control signal for software update Digital signal, low active
5 M5V Reference potential to P5V
6 P5V
7 RS232 TxD Transmit data via RS232
8 RS485 N
9 M_RS232/485
Serial interface X300
Switch
S1 SCom1 (X300): Bus terminating resistor
• •
open Resistor open
• •
closed Resistor closed
S2 SCom2 (X101/10,11): Bus terminating resistor
• •
open Resistor open
• •
closed Resistor closed
Operating Instructions
Meaning
+10 V supply for ext.
potentiometer
-10 V supply for ext.
potentiometer
USS bus connection SCom1
USS bus connection SCom1
2 2
to 1.5 mm
Meaning
Not connected
Data via RS485
5 V aux. voltage supply
Data via RS485
Digital ground (choked)
Meaning
Connecting-up
Range
+10 V ± 1.3 %,
Imax = 5 mA
-10 V ± 1.3 %,
Imax = 5 mA
RS485
RS485
RS485
RS485
(AWG 16)
Range
RS232
RS485
0 V
+5 V, Imax = 200 mA
RS232
RS485
7-13
