Siemens simovert masterdrives Betriebsanleitung Seite 239

05.2006
LED red
Fault
LED green
Run
I
ON key
OFF key
O
Jog key Jog
Fig. 8-3
Fault
Run
I
O
P
USS-Bus
Jog 7 8 9
4 5 6
1 2 3
0 +/- Reset
OP1S
Connecting cable
5
9
4
8
3
7
2
6
1
OP1S side:
9-pole SUB D socket
Fig. 8-4
NOTE
In the as-delivered state or after a reset of the parameters to the factory
setting, a point-to-point link can be adopted with the OP1S without any
further preparatory measures and parameterization can be
commenced.
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES
LCD (4 lines x 16 characters)
Reversing key
Raise key
Lower key
P
Key for toggling between control levels
7 8 9
0 to 9: number keys
4 5 6
1 2 3
+/- Reset key (acknowledge)
0
Reset
Sign key
View of the OP1S
5
9
4
8
3
7
2
6
1
Unit side:
9-pole SUB D connector
The OP1S directly connected to the unit
Operating Instructions
Parameterization
9-pole SUB-D connector
on rear of unit
8-11
