05.2006
8

Parameterization

It is possible to parameterize the units of the SIMOVERT
MASTERDRIVES series by various methods of parameter input. Every
unit can be set via the dedicated parameterizing unit (PMU) without the
need to use additional components.
Each unit is supplied with the user software DriveMonitor and
comprehensive electronic documentation on a CD. In the case of
installation on a standard PC the units can be parameterized via the
serial interface of the PC. The software provides extensive parameter
aids and a prompted start-up function.
The unit can be further parameterized by entering parameters with the
OP1S manual operator panel and via a controller at the field bus level
(e.g. Profibus).
NOTE
In firmware V.20 (for performance 2 units) BICO parameters can also
be changed in the "Run" drive status (see also parameter list
"Changeable in"). In contrast to firmware v1.x in which BICO
parameters could only be changed in the "Ready" drive status,
structural changes can also be made on performance 2 units with
firmware V2.0 during running operation.
WARNING
Unintentional axis movements may occur as a result of undesired
changes to BICO parameters in the "Run" drive status.
8.1

Parameter menus

Parameters with related functions are compiled in menus for structuring
the parameter set stored in the units. A menu thus represents a
selection out of the entire supply of parameters of the unit.
It is possible for one parameter to belong to several menus. The
parameter list indicates which individual menus a parameter belongs to.
Assignment is effected via the menu number allocated to each menu.
Siemens AG 6SE7087-6JK50
SIMOVERT MASTERDRIVES Operating Instructions
Parameterization
8-1
