Parameterization
Input in Motor order
P097 number
(MPRD)
30 1PH7186-2_L
31 1PH7224-2_B
32 1PH7224-2_D
33 1PH7224-2_U
34 1PH7224-2_L
35 1PH7226-2_B
36 1PH7226-2_D
37 1PH7226-2_F
38 1PH7226-2_L
39 1PH7228-2_B
40 1PH7228-2_D
41 1PH7228-2_F
42 1PH7228-2_L
43 1PL6184-4_B
44 1PL6184-4_D
45 1PL6184-4_F
46 1PL6184-4_L
47 1PL6186-4_B
48 1PL6186-4_D
49 1PL6186-4_F
50 1PL6186-4_L
51 1PL6224-4_B
52 1PL6224-4_D
53 1PL6224-4_F
54 1PL6224-4_L
55 1PL6226-4_B
56 1PL6226-4_D
57 1PL6226-4_F
58 1PL6226-4_L
59 1PL6228-4_B
60 1PL6228-4_D
61 1PL6228-4_F
62 1PL6228-4_L
63 1PH4103-4_F
64 1PH4105-4_F
65 1PH4107-4_F
66 1PH4133-4_F
8-50
Rated Pole pair Current
speed number I [A]
n
n [rpm] Z
n p
2900 2 206.0
400 2 88.0
1150 2 160.0
1750 2 203.0
2900 2 274.0
400 2 114.0
1150 2 197.0
1750 2 254.0
2900 2 348.0
400 2 136.0
1150 2 238.0
1750 2 342.0
2900 2 402.0
400 2 69.0
1150 2 121.0
1750 2 166.0
2900 2 209.0
400 2 90.0
1150 2 158.0
1750 2 231.0
2900 2 280.0
400 2 117.0
1150 2 218.0
1750 2 292.0
2900 2 365.0
400 2 145.0
1150 2 275.0
1750 2 350.0
2900 2 470.0
400 2 181.0
1150 2 334.0
1750 2 470.0
2900 2 530.0
1500 2 20.2
1500 2 27.3
1500 2 34.9
1500 2 34.1
Operating Instructions
Voltage Torque
U [V] M [Nm]
n n
385 333
268 725
385 670
395 600
395 490
264 935
390 870
395 737
390 610
272 1145
390 1070
395 975
395 708
300 585
400 540
400 486
400 372
290 752
400 706
400 682
390 494
300 1074
400 997
400 900
400 675
305 1361
400 1287
400 1091
400 889
305 1719
400 1578
400 1446
400 988
350 48
350 70
350 89
350 95
6SE7087-6JK50 Siemens AG
SIMOVERT MASTERDRIVES
05.2006
Frequency
f [Hz]
n
97.3
14.0
38.9
58.9
97.3
14.0
38.9
58.9
97.2
13.9
38.9
58.8
97.2
14.4
39.4
59.3
97.6
14.3
39.4
59.3
97.5
14.2
39.1
59.2
97.5
14.0
39.2
59.1
97.4
14.0
39.2
59.0
97.3
52.9
53.1
52.8
51.9
