BIONIC NECK SUPPORT - IMPORTANT USER INFORMATION
1. Shoulder Mounting
2. Shoulder Pad
3. Chin Support
4. Quick Release Locking System ( QRLS)
5. X Strap Hooks
6. Rear Tail Section
7. Chin Frame Pads
8. Pivot Key
Note: Pad Set consists of (2), (11) and (16).
Figure 2 – Quick Release Locking System: rapid and efficient fitting/removal, which offers a
secure and convenient attachment which can also be quickly opened in case of emergency.
3. Rear Stabilizer with comfort ergonomic design.
Rear Stabilizer (10): developed to promote PFR (progressive force relief) and dissipate ex-
treme energy loads. Stabilizer pads are designed to transfer impact stress loads away from
spine (thoracic vertebrae).
Figure 3 – Rear Stabilizer / Attachment Plate,
Progressive Force Relief (PFR)
9. Attachment Plate
10. Rear Stabiliser
11. Chest Pads
12. X Strap
13. Size Adapters
14. Rear Frame
15. Front Frame Members
16. Rear Stabiliser Pads
Figure 4 – Rear Stabilizer Pads, with
comfort ergonomic design.
– Size adapters.
Figure 5
4. Setting up your Bionic Neck Support
Alpinestars recommends that fitting of the BNS be carried out while wearing the
Figure 5 – Size adapters.
helmet and riding clothing normally used when riding.
Importance of the right helmet
The brand of helmet you wear does not change how the device fits to your body, but can
noticeably influence head movement, as well as alter the gap between the helmet & BNS.
Some helmets which sit very low at the rear could restrict movement of the head with a
properly fitted BNS. Furthermore, the helmet you wear must be correctly sized. A helmet
which is too small (e.g. one where the bottom of the rider's jaw is not inside or in line with
the helmet shell when fastened) could leave too big a gap rendering the Bionic less effective
and exposing the jaw to injury. A helmet which is too large will reduce head movement as
well as compromise the safety of your head. This is why it is important to fit the support with
the helmet you normally ride with.
The BNS Pro & Tech 2 is designed to provide a highly customizable, secure and personalized
fit. The SAS (size adapter system) provides an adjustable and versatile BNS fit in size ranges
XS-M and L-XL. Interchangeable EVA lycra-laminated foam padding kits (6mm and 10mm)
for rear, front and shoulders allow fine- tuning adjustment of BNS to rider's specific needs.
It also aids compatibility with other body protection systems. Strap System: BNS supplied
with the X Strap System which allows a small, light strap worn over or under the jersey to
secure the device to the rider.
Fitting Procedure
The length of the adapters (13) dictates the size of the BNS. Table 1 below provides a guide
to begin the fitting process. Find your corresponding size on the left of the table then select
the correct adapter (13) size for the BNS on the right depending on how thick or thin (T) your
chest is:
