2 System description

The CURIS flow is an irrigation pump for the supply of isotonic saline solution to the surgical area
®
with the integrated peristaltic pump, either with an insertable bipolar cord / tubing set together and
a bipolar irrigation instrument or with an irrigation tubing. The selected flow setting is displayed on
the irrigation pump and can be changed using a control element. It can be used in conjunction with
the CURIS 4 MHz radiofrequency generators from Sutter Medizintechnik GmbH or on its own with
®
a corresponding one-pedal footswitch with push-button, available as an option (see accessories
in Chapter 8).
Scope of delivery:
1x CURIS flow Irrigation pump (REF: 350950)
®
1x US mains cable (REF: 93001047)
1x EU mains cable (REF: 93006957)
1x CURIS RF Generator interconnecting cable (REF: 93008120)
®
1x Instructions for use (REF: 899080-XX)
1x CURIS flow IV pole mounting bracket (REF: 360901)
®

2.1 Function and meaning of the display and control elements

Front of the device:
8
7
1
1 Power switch
Turns the irrigation pump on and off
2 Display
Shows the selected flow setting
3 Flow setting control element
Turning clockwise increases, turning counterclockwise decreases the flow rate
4 Flush function button
Pressing the "Flush" button activates the irrigation pump with a predefined, fixed flow setting
(max. flow rate)
5 LED status indicator
Lights up red and indicates a device defect
6 Pause function button
Pressing the "Pause" button activates pause mode, supply of irrigation fluid is paused and the
flow setting on the display starts flashing
3
2
3
4
6
5
