9. START/STOP (USB DRIVE MODE)
Push the [START/STOP] key to initiate start
and stop of a recording when GL860 is in the
Free Running mode.
If the key is pushed while turning the power to
the GL860 on, the unit will switch from the USB
connection to USB DRIVE mode.
* For more information about the Drive Mode
of the USB, refer to the User's Manual.
10. REVIEW
Push the [REVIEW] key to replay recorded
data.
If the GL860 is in the Free Running mode, data
files that have already been recorded will be
displayed.
If the GL860 is still recording data, the data is
replayed in a 2-screen format.
* A data replay operation will not be performed
if data has not been recorded.
11. DISPLAY
Push the [DISPLAY] key to switch the display.
Tips
•Waveform + Digital
Waveform
Default screen when the GL860 is
+
initially turned on with both the
Digital
waveforms and digital values.
•Full-screen Waveform
Full-screen
Displays expanded waveforms
Waveform
only.
•Digital + Calc
Digital
Displays large-size digital values
+
and calculation processing results.
Calc
Use the
switch digital display modes.
•Alarm History
Alarm
Displays the alarm history screen.
History
*Only when alarm history is ON.
* For more information, refer to the User's Manual.
12. CURSOR (ALARM CLEAR)
Press the [CURSOR] key to switch between
the A and B cursors during a data replay
operation.
If the Alarm setting has been specified as
"Alarm Hold", press this key to clear the alarm.
The alarm settings are made in the "ALARM"
menu.
12. CURSOR (ALARM CLEAR)
Press the [CURSOR] key to switch between
the A and B cursors during a data replay
operation.
If the Alarm setting has been specified as
"Alarm Hold", press this key to clear the alarm.
The alarm settings are made in the "ALARM"
menu.
13. FILE
This is used to operate the internal memory
and SD memory card, or for file operation,
screen copy and save/load current settings.
14. FUNC
[FUNC] key allows you to perform frequently
used functions every time.
key or key to
