Top Panel
Power jack for humidity sensor
Humidity sensor
(Option: when using the B-530)
SD memory card
Front Panel
AC adapter jack
USB interface terminal
LAN interface terminal
Bottom Panel
Battery pack can be installed
(Battery pack is the option B-573)
Name of parts
Analog signal input terminals
Wireless LAN
connection terminal
Wireless unit
(Option: when using the B-568)
External input/output terminals
• LOGIC/PULSE
• EXT TRIG/SAMPLE
• ALARM
Input/output cable for GL
(Cable is the option B-513)
Monitor
Battery cover
• Standard 20CH screw terminal (B-563)
• Standard 20CH screwless terminal (B-563SL)
• Standard 30CH screwless terminal (B-563SL-30)
• Withstand high-voltage high-precision terminal (B-565)
GND terminal
Operation status LED
• POWER
• START
• CHARGE
Control panel keys
3
Power switch
Tilt foot
Label
