GRAPHTEC midi LOGGER GL860 Schnellstartanleitung Seite 2

Thank you for choosing Graphtec midi LOGGER GL860.
The Quick Start Guide is to assist with the basic operations.
Please refer to the USER'S MANUAL (PDF) for more details.
To make measurements using the GL860, the following terminal units are required in addition to
the GL860 main unit.
• Standard 20CH screw terminal (B-563)
• Standard 20CH screwless terminal (B-563SL)
• Standard 30CH screwless terminal (B-563SL-30)
• Withstand high-voltage high-precision terminal (B-565)
Check the exterior condition
Check the exterior of the unit to ensure that there are no cracks, defects, or any other damages
before use.
Accessories
• Quick Start Guide: 1
• AC cable/AC adapter: 1
Files stored in the internal memory
• GL860 User's Manual
• GL28-APS (Windows OS software)
• GL-Connection (Waveform viewer and Control software)
* When the internal memory is initialized, the stored files are deleted. If you have deleted the
User's Manual and the supplied software from the internal memory, please download them from
our website.
Registered trademarks
Microsoft and Windows are registered trademarks or brands of the US Microsoft Corporation in
the USA and other countries.
.NET Framework is a registered trademark or trademark of US Microsoft Corporation in the USA
and other countries.
About the User's Manual and Accompanying Software .............................................................. 2
Name of parts ............................................................................................................................ 3
Connection Methods ................................................................................................................. 4
Safety Guide for using GL860 ................................................................................................... 5
About the Control Panel Keys ................................................................................................... 7
About the Menu Screens ........................................................................................................... 9
Accompanying Software .......................................................................................................... 11
Introduction
Contents
1
