Function 03 Read Single Register &
Function 06 Write Single Register
Register Parameter
0021 Alignment of the display content
0022 Display contrast
0023 Backlight brightness
0024 Representation on display
0028 Measuring range start
0029 Measuring range end
0031 Display unit Display Sensor unit
0032 Free measuring range /
15 fixed measuring ranges of the sensor
0033 Capture period
min/max values (volatile)
0034 Number of values
for calculating floating averages
®
LCD - SHD -Modbus | Configuration via Modbus
Data Type Value
Signed 16 Bit 0...3
Signed 16 Bit 10...40
Signed 16 Bit 0...11
Signed 16 Bit 0...2
Signed 16 Bit 0...8000
Signed 16 Bit 0...8000
Signed 16 Bit 0...5 /
30...35
Signed 16 Bit 0...15
Signed 16 Bit 1
6
12
24
0
Signed 16 Bit 0...10
25
Range
0 =
0° (default)
1 = 90°
2 = 180°
3 = 270°
10...40 (default 26)
0 = off
1...10 = dark...bright (default 8)
11 = auto
0 = BIG
1 = pressure + Sensor value
(default)
2 = pressure + min/max value
0 ... 80,00 bar (default 0)
0 ... 80,00 bar (default 8000)
Sensor bar Sensor psi
0 = bar 30 = bar
(default) (default)
1 = kPa 31 = kPa
2 = mWC 32 = mWC
3 = psi 33 = psi
4 = inWC 34 = inWC
5 = atm 35 = atm
for bar for psi
0 = free up to 0 = free up to
80.0 1200
(default) (default)
1 = 0.5 1 = 10
2 = 1 2 = 25
3 = 2.5 3 = 50
4 = 5 4 = 100
5 = 10 5 = 150
6 = 15 6 = 200
7 = 20 7 = 250
8 = 25 8 = 300
9 = 30 9 = 400
10 = 35 10 = 500
11 = 40 11 = 600
12 = 45 12 = 700
13 = 50 13 = 800
14 = 55 14 = 900
15 = 60 15 = 1000
1 = 1 h
6 = 6 h
12 = 12 h
24 = 24 h (default)
0 = ∞
1 = 1 value (approx. 1 s)
2 = 2 values (approx. 2 s) (default)
etc. until
10 = 10 values (approx. 10 s)
