NOTE!
Risk of damage!
If incorrectly stored or undrained fuel is used, the car-
burettor may become clogged or engine operation may
be affected.
- Put unused fuel in an airtight vessel and store it in
a dark, cool room.
- Use only designated and approved vessels for the
transport and storage of fuel.
NOTE!
Mowing with the petrol ride-on lawn mower is only
possible with the catch basket inserted. Otherwise,
the engine will switch off for safety reasons after the
mower is switched on!
10.1 Fill up with engine oil and insert battery (Fig.
1 + 11 + 12)
m Attention!
The engine does not come with oil in it. Therefore,
ensure that you add oil before starting it up. Use
multigrade oil (SAE 30) for this purpose. The oil
level in the engine must be checked each time be-
fore mowing.
1.
Open the oil tank cap (21) and fill the tank with oil
(SAE 30) using the funnel. Note the max. filling
capacity.
2.
Then close the oil tank cover (21) again.
3.
Insert the battery (5a) by sliding it along the guide
rail into the device. It clicks into place audibly.
m DANGER!
Risk of fire and explosion!
When filling, fuel may ignite and even explode. This
can lead to severe burns or death.
- Switch off the engine and let it cool down.
- Keep heat, flames and sparks away.
- Only fill up with fuel outdoors.
- Wear protective gloves.
- Avoid contact with skin and eyes.
- Start the product at a distance of at least 3 m from
the fuel filling point.
- Watch out for leaks. If petrol is leaking, do not start
the engine.
m WARNING!
Health hazard!
Inhaling petrol/lubricant vapours may lead to severe
health damage, loss of consciousness and, in extreme
cases, to death.
- Do not inhale petrol/lubricant vapours.
54 | GB
www.scheppach.com · service@scheppach.com
- Operate the product outdoors only.
NOTE!
Product damage
Using the product without or with too little engine and
gearbox oil can result in engine damage.
- Fill with petrol and oil before commissioning. The
product is supplied without engine and gearbox oil.
NOTE!
Environmental damage!
Spilled oil can pollute the environment permanently.
The liquid is highly toxic and can quickly lead to water
pollution.
- Fill/empty oil only on level, paved surfaces.
- Use a filling nozzle or funnel.
- Collect drained oil in a suitable container.
- Wipe up spilled oil carefully immediately and dis-
pose of the cloth according to local regulations.
- Dispose of oil as per local regulations.
10.2 Filling up with petrol (Fig. 13)
m Attention!
The petrol ride-on lawnmower is delivered without
petrol. It is therefore essential to fill with petrol be-
fore commissioning. Use Super E5 / E10 petrol for
this purpose.
1.
Fold the driver's seat (1) over.
2.
Clean the area surrounding the filling area. Impuri-
ties in the tank lead to operational faults.
3.
Carefully open the tank cover (22) so that any pos-
sible overpressure can be relieved.
4.
Fill the tank with petrol (Super E5 / E10) using a
funnel. Note the max. filling capacity. Carefully fill
the petrol up to the lower edge of the filling nozzle.
5.
Close the tank cover (22) again. Ensure that the
fuel cap is tightly sealed.
6.
Clean the fuel cap and the surroundings.
7.
Check the tank and fuel lines for leaks.
8.
Move at least three meters away from the refuel-
ling area before starting the engine.
10.3 Check the tyre pressure
The correct tyre pressure is the essential prerequisite
for a perfectly balanced cutting tool and thus also for an
evenly mown lawn.
1.
Check the tyre pressure with a commercially avail-
able foot pump at regular intervals.
