2.
If necessary, refill with air using a commercially
available foot pump (not included in scope of de-
livery). The correct tyre pressure is 1.5 bar in the
front wheels (9) and 1.8 bar in the rear wheels (6).
Note: If you notice that the tyres or wheels are dam-
aged, please contact the customer service or a spe-
cialist workshop.
10.4 Checking the mowing unit contact switch
(Fig. 1)
The mowing unit contact switch ensures that the engine
cannot be started when the mowing unit is engaged.
1.
Engine is off.
2.
Sit on the driver's seat (1).
3.
Press the brake pedal (13) down completely and
actuate the locking brake (12).
4.
Engage the mowing unit (8) by pushing the lever
for the mowing unit (3) forward and pressing it to
the right until it engages.
5.
Try to start the engine (ignition key (18a) in "Start"
position).
6.
The engine must not start!
Note: If you notice that the contact switch is not work-
ing correctly, please contact the customer service or a
specialist workshop.
10.5 Checking the seat contact switch (Fig. 1 + 4)
The seat contact switch ensures that the motor switch-
es off as soon as there is no one in the driver's seat.
1.
Sit on the driver's seat (1).
2.
Depress the brake pedal (13) and activate the lock-
ing brake (12).
3.
Start the engine and let it run.
4.
Take the weight off the driver's seat (1) by standing
up (do not get off!)
5.
The engine must switch off!
Note: If you notice that the contact switch is not work-
ing correctly, please contact the customer service or a
specialist workshop.
10.6 Checking the catch basket contact switch
(Fig. 1)
The catch basket contact switch (2) ensures that the
engine switches off as soon as the catch basket (2)
is not correctly hooked in when the mowing unit is
switched on.
1.
Sit on the driver's seat (1).
2.
Depress the brake pedal (13) and activate the lock-
ing brake (12).
3.
Start the engine and let it run.
www.scheppach.com · service@scheppach.com
4.
Engage the mowing unit (8) by slowly pushing the
lever for the mowing unit (3) forward and pressing
it to the right until it engages.
5.
Lift the empty catch basket (2) slightly.
6.
The engine must switch off!
Note: If you notice that the contact switch is not work-
ing correctly, please contact the customer service or a
specialist workshop.
10.7 Check the blade stop device
When the mowing unit is released, a braking process
is triggered automatically and simultaneously, bringing
the mowing blade to a standstill within a few seconds.
A running blade produces clearly perceptible wind
noises. The running of the blade is signalled by the
wind noise generated and can thus be controlled.
Note: If you notice that the blade stopping device is not
working correctly, please contact the customer service
or a specialist workshop.
11. Operation
m Attention!
Always make sure the product is fully assembled
before commissioning!
11.1 Operating times
Please comply with statutory regulations to lawnmower
operating times, which may vary from location to lo-
cation.
Familiarise yourself with the controls and the control
parts as well as with the use of the device.
In particular, the user must know how to stop the de-
vice's working tool and combustion engine quickly.
The device may only be used by persons who have
read the user manual and who are familiar with the
handling of the device. Prior to initial commissioning,
the user must seek expert and practical instruction.
The user must be told by the seller or another qualified
person how to use the device safely.
During this instruction, the user should be made aware
in particular,
• that extreme care and concentration are necessary
when working with the device.
