GARANT XControl
de
Variable
FEED RATE
Back to Siemens automated operation [} Page 13]
en
6.3.5. Auxiliary cycle L_START(1)
Probe cycle Function
bg
L_START(1) XControl switches to
standby mode after 10
minutes without
measurement. React-
da
ivation of wireless
connection is auto-
matic upon call-up of
a probe cycle, but
fi
takes approx. 15
seconds. Auxiliary
cycle L_START(1) can
be used to manually
reactivate the wireless
fr
connection, in order
to reduce non-pro-
ductive times.
Example
it
L_START(1) Call-up of auxiliary cycle. Start of reactivation.
⁝ Tool positioning 5 mm above the XControl
L_BREAK Call-up of the probe cycle (breakage monitoring)
hr
Back to Siemens automated operation [} Page 13]
6.3.6. Auxiliary cycle L_RESET(1)
Probe cycle Function
lt
L_RESET(1) After 100 probe pro-
cesses, the wireless
nl
connection is deactiv-
ated. The reactivation
of the wireless con-
nection is automatic
upon call-up of a
no
probe cycle and takes
15 seconds. Through
call-up of the auxiliary
cycle, the counter of
pl
the measurements is
reset and the wireless
connection is main-
tained.
pt
Example
L_RESET(1) Call-up of the auxiliary cycle, counter is reset.
Back to Siemens automated operation [} Page 13]
ro
6.4. HEIDENHAIN AUTOMATIC OPERATION
The parameters Q1899-Q1940, QR59-QR67 are overwritten during the measurement
process. The sub-program collection comprises standard measurement cycles for the
controller Heidenhain iTNC 530 / TNC 640. The sub-program folders must be saved
sv
directly in path TNC:\. The sub-programs are configured for the G17 level. The probe
cycles work exclusively with the XControl.
Cycle
sk
sl
6.4.1. Probe cycle BSP_L_POS
Probe cycle Function
es
BSP_L_POS. The program
H. BSP_L_POS.H is for de-
termining the position
cs
of the XControl in the
machine coordinates
system. The reference
tool must be posi-
hu
tioned centrally in the
tool axis with a dis-
14
Value Meaning
0 - 3 Probing feed rate in mm/
min
Note Program code
L_START(1)
Note Program code
L_RESET(1)
Link
Note Program code
The program is only BSP_L_POS.H
required in the follow-
ing instances: - When
initially positioning
the XControl in the
working area of the
machine. - Each time
tance of approx. 5 mm the XControl is reposi-
to the contact point tioned in the working
above the XControl. area of the machine.
The two other axes are
not travelled in the
probing process.
Example
0 BEGIN PGM BSP_L_POS MM
1 ;================================
2 ; Calibration tool overall length
3 Q1903 = 5000
4 ;================================
5 ; M19 / M20 SPINDLE ORIENTATION
6 Q1913 = 19
7 ;================================
8 CALL PGM TNC:\X_CONTROL\L_POS.H
9 M30
10 ND PGM BSP_L_POS MM
For the above-mentioned variables, the values from the following table can be used.
Variable Value
Q1903
ℝ≠0
Q1913 ℤ>0
Example/program code for variable Q1903 and Q1913
0 BEGIN PGM BSP_L_POS MM
1 ;================================
2 ; Calibration tool overall length
3 Q1903 = 128.44
4 ;================================
5 ; M19 / M20 SPINDLE ORIENTATION
6 Q1913 = 19
7 ;================================
8 CALL PGM TNC:\X_CONTROL\L_POS.H
9 M30
10 END PGM BSP_L_POS MM
The position of the XControl in the tool axis is determined with a reference tool with
the length 128.44 mm. On the controller, it is possible to check in the file folder
XCONTROL in the file L_L_POS1.TAB whether the reference position of the XControl
in the tool axis was saved.
When reconfiguring the XControl, the existing reference value is moved to row 1 of
column HEIGHT and the current reference value is written in row 0. A values compar-
ison is possible.
L_POS1.TAB
NR HEIGHT
0 -560.521
1 5000
Back to Heidenhain automatic operation [} Page 14]
6.4.2. Probe cycle BSP_L_BREAK
Probe cycle Function Note
BSP_L_BREA BSP_L_BREAK.H is for The controller reports
K. monitoring the tool in "tool breakage" if the
the spindle. The tool calculated tool length
must be positioned D1 from the tool
centrally in the tool memory shows a delta
axis with a distance of of -2 mm. The control-
approx. 5 mm to the ler reports a "swarf
contact point above nest" if the calculated
the XControl. The two tool length D1 from
other axes are not the tool memory
travelled in the prob- shows a delta of
ing process. +1.2 mm.
Example
0 BEGIN PGM BSP_L_BREAK MM
1 FEED RATE FACTOR;
Meaning
Exact length of the refer-
ence tool.
Value for spindle orienta-
tion M19 => Q1913=19
M20 => Q1913=20
COMMENT
GTH
Value
Program code
BSP_L_BREAK.H
