• Special care must be taken when using jumper ca-
bles. Follow relevant instructions to avoid damage to
the device (in particular, do not operate the starter
for more than 10 seconds).
• Never open the battery and do not drop it.
• Always charge the battery in a closed room with good
ventilation, dry and protected against the weather.
• Do not short-circuit battery connections.
• Deformed or defective (leaking) batteries must not
be used and must be replaced and disposed of in an
environmentally friendly manner. Observe the coun-
try-specific regulations.
• If the batteries are defective, liquid may leak out.
Avoid contact! In case of accidental contact, rinse
with water. If the liquid gets into your eyes, seek ad-
ditional medical attention. Leaking battery fluid can
cause skin irritation, burns and chemical burns.
• Regularly visually inspect the connection cables on
the battery for damage. Have damaged cables re-
placed by a specialist.
• Never bypass the fuses. Never use a fuse with a rat-
ing other than the prescribed rating (amperes).
Residual risks
The device is state-of-the-art and has been built in ac-
cordance with the recognised technical safety rules.
However, individual residual risks can arise during op-
eration.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "Safety In-
structions" and the "Intended Use" together with the
operating manual as a whole are observed.
• Avoid accidental start-ups of the power generator.
• Use the device in the way that is recommended in
this operating manual. This is how to ensure that
your power generator provides optimum perfor-
mance.
m WARNING! This power tool generates an electro-
magnetic field during operation. This field can impair
active or passive medical implants under certain cir-
cumstances.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
6. Technical data
Protection category
Continuous output power
P (COP) (230 V) (S1)
n
Continuous output power
P (COP) (400 V 3~) (S1)
n
Max. power P
(230 V) (S2 5min)
Max. power Pmax
(400 V 3~) (S2 5min)
Rated voltage U
Rated current I
Rated current I
Rated current I
Frequency F
Performance class
Active power factor φ
Quality class
Drive motor type
Displacement
Max. power (engine)
Fuel
Tank contents
Engine oil type
Oil volume (approx.)
Weight
Temperature T
Spark plug type
Max. installation altitude
(above sea level)
Battery type
Battery capacity
Subject to technical changes!
Operating mode S1 (continuous operation)
The machine can be operated continuously with the
specified power.
www.scheppach.com
max
230 V~ / 400 V 3~
n
(12 V DC)
n
(230 V)
n
(400 V 3 )
~
n
n
Single phase / Three
4-stroke, 1 cylinder,
Super E10 petrol
max
F6RTC / F7RTC
IP23M
2.0 kW
5.0 kW
2.2 kW
5.5 kW
8.3 A
9 A
9 A
50 Hz
G1
phase: 1 / 0.8
A
air-cooled
420 cm
3
9.0 kW
25 l
10W30
1100 ml
80.7 kg
40 C
°
1000 m
Lead acid
9 Ah
