Glue EPDM gasket around hatch hole (see
3
detail for cutting end join edges).
HOW TO CUT EPDM GASKET TO AVOID
!
WATER FILTRATION INTO THE CABIN
A- Glue gasket, keeping 100 mm of protection
paper at each side.
B- Remove the two pieces of paper.
C- Glue by pressing both ends.
B
Gasket
OUTSIDE CABIN:
4
Position Compact in sun hatch hole.
Caution! When positioning the unit
above the hatch gap, check that the
wastewater run-offs are not blocked by
the EPDM seal.
Gasket
Remove
3
A
Gasket
100 mm Approx. (protection paper)
C
Gasket
4
Sun hatch
21
EN
15 mm
Gasket
Cabin roof
Gasket
