2:3 TECHNICAL DATA

Dimensions: Height
Boiler dimensions: 305 mm
Rec. min. installation dimensions:
310 mm
14 kg (without fluid)
Weight:
Gas: Propane
Output Stage 1: 3.3 kW
Consumption: 245 g/h
Output Stage 2: 5.5 kW
Consumption: 405 g/h
Gas pressure: I 28–30/37 mbar
3+
I
3B/P
Fresh water connection OUT
Electric element 2 kW
Electric element 1 kW
Width Length
340 mm 490 mm
400 mm 500 mm
Butane
3.8 kW
275 g/h
6.4 kW
460 g/h
30 mbar
Ethylene glycol fluid OUT
Fresh water connection IN
Fluid volume/pressure
Fluid volume, ethylene glycol fluid: 3.5 litres
Fluid volume, fresh water:
Max pressure, heating system:
Max pressure, fresh water:
System temperature:
230 V ~
Output, element:
(2 or 3 kW)
12 V DC
Power consumption:
Fuse:
Electronics
Combustion fan
Solenoid valve
Ethylene glycol fluid IN
8.4 litres
0.05 MPa (0.5 bar)
0.3 MPa (3.0 bar)
85°C max.
1 x 1050 W
1 x 2100 W
1 amp (max.)
3.15 amp
7
