Aluminum - 105 A - Air - Hypertherm Powermax65 SYNC Bedienungsanleitung

Metric
Material Thickness Cut Height
mm mm
6
8
10
12
16 3.2
20
25
30
32
English
Material Thickness Cut Height
inches inches
1/4
3/8
1/2
5/8
3/4 0.125
7/8
1
1-1/8
1-1/4
Gas flow rate – slpm / scfh
236 / 500
311 / 660
Powermax65/85/105 SYNC
Aluminum – 105 A – Air
428895
ohmic sensing ring
Initial Pierce Height Pierce Delay
mm % seconds
0.5
6.4 200 0.8
1.0
1.3
Edge Start
Initial Pierce Height Pierce Delay
inches % seconds
0.5
0.8
0.250 200
1.0
1.3
Edge Start
Hot (cutflow)
Cold (postflow)
Cut Charts Guide 810500MU
428936
Best Quality Highest Production
Cut Speed Arc Voltage Cut Speed
mm/min volts mm/min
5660 146 6730
3760 148 4500
2590 149 3230
1930 151 2490
1320 156 1650
1020 160 1190
660 166 810
430 172 560
380 174 510
Best Quality Highest Production
Cut Speed Arc Voltage Cut Speed
in/min volts in/min
223 146 265
110 149 136
70 152
52 155 66
43 159 50
34 162 40
26 166
19 170
15 174
Revision 2 Multilingual
Cut Charts
Kerf Width
Arc Voltage
volts mm
146 2.3
147 2.4
148 2.4
149 2.5
153 2.5
157 2.6
163 2.7
168 3.0
170 3.1
Kerf Width
Arc Voltage
volts inches
146 0.093
148 0.096
91 150 0.098
153 0.100
156 0.102
159 0.105
31 163 0.109
24 167 0.114
20 170 0.122
43
