Cut Charts
Metric
Material Thickness Cut Height
mm mm
3
4
6
8
10
3.2
12
16
20
25
30
English
Material Thickness Cut Height
inches inches
10 GA
3/16
1/4
3/8
1/2
5/8 0.125
3/4
7/8
1
1-1/8
1-1/4
Gas flow rate – slpm / scfh
212 / 450
264 / 560
44
Mild Steel – 85 A – Air
428895
ohmic sensing ring
Initial Pierce Height Pierce Delay
mm % seconds
0.0
3.8 120 0.2
0.5
4.8 150
1.0
6.4 200 1.5
Edge Start
Initial Pierce Height Pierce Delay
inches % seconds
0.2
0.150 120
0.5
0.188 150
1.0
0.250 200 1.5
Edge Start
Hot (cutflow)
Cold (postflow)
Multilingual Revision 2
428934
Best Quality
Cut Speed Arc Voltage
mm/min volts
6930 134
5560 134
3560 135
2360 136
1630 137
1240 138
840 142
580 147
360 153
200 159
Best Quality
Cut Speed Arc Voltage
in/min volts
250 134
185 134
130 135
70 136
46 139
34 142
25 146
19 150
13 153
9 157
6 161
810500MU Cut Charts Guide
Highest Production
Kerf Width
Cut Speed Arc Voltage
mm/min volts mm
9580 131 1.5
7140 132 1.7
4220 134 1.9
2820 135 2.1
2030 137 2.3
1520 138 2.4
970 142 2.6
660 145 2.8
430 150 3.0
300 155 3.4
Highest Production
Kerf Width
Cut Speed Arc Voltage
in/min volts inches
334 132 0.063
226 133 0.070
153 134 0.077
86 136 0.088
55 139 0.096
39 142 0.103
28 144 0.108
22 147 0.114
17 150 0.120
13 153 0.128
10 157 0.139
Powermax65/85/105 SYNC
