Required space
Total weight [kg]
Spindle speeds [ min
Spindle speeds [ min
Stage number
Environmental conditions temperature
Environmental conditions
Relative humidity
Operating material gear
Operating material
Toothed rod and drill column
Coolant equipment
2.1
Emissions
CAUTION!
The user must wear noise protection and hearing protection.
The A-weighted sound pressure level L
The A-weighted sound power level L
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Furthermore, the noise emission also depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
EN
DH26GT | DH28GS | DH32GS
86
DH 26 GT
Keep a work area of at least one metre around the machine free for opera-
158
75 ǀ 150 ǀ 250
-1
] at ~50Hz
420 ǀ 500 ǀ 840
1450 ǀ 2900
90 ǀ 180 ǀ 300
-1
] at ~60Hz
500 ǀ 600 ǀ 1000
1740 ǀ 3480
5 - 35 °C
25 - 80 %
Commercial Operating
material
anti-friction bearing
grease
is 83 to 86 dB.
pA
is 95 to 98 dB.
WA
Translation of original instruction
DH 28 GS
tion and maintenance.
175
75 ǀ 150 ǀ 250
420 ǀ 500 ǀ 840
1450 ǀ 2900
90 ǀ 180 ǀ 300
500 ǀ 600 ǀ 1000
1740 ǀ 3480
8
8
5 - 35 °C
25 - 80 %
-
-
-
-
DH 32 GS
312
75 ǀ 110 ǀ 240
360 ǀ 420 ǀ 620
1330 ǀ 2000
90 ǀ 130 ǀ 290
430 ǀ 500 ǀ 740
1600 ǀ 2400
8
5 - 35 °C
25 - 80 %
Water mixable, nebular
arm, high flash point,
nitrite content of the
emulsion is less than
20 mg/l
Filling quantity 6 litres
Technical data
Version 1.2.9 - 2021-09-28
