VACON® 1000
Bedienungsanleitung
Kabel/Sammelschiene
Ausgangsleistungskabel
Transformatoreingangskabel
Transformatorausgangskabel
138 | Danfoss A/S © 2021.06
Kabel-/Sammel- Klemmleisten-
schienengröße typ
2/0 AWG TLK70-8
3/0 AWG TLK95-10
4/0 AWG TLK120-10
250 kcmil TLK150-10
300 kcmil TLK185-10
400 kcmil TLK240-10
600 kcmil TLK400-12
750 kcmil TLK400-12
9 AWG TLK10-8
5 AWG TLK25-8
2 AWG TLK35-8
2/0 AWG TLK70-8
3/0 AWG TLK95-10
4/0 AWG TLK120-10
250 kcmil TLK150-10
300 kcmil TLK185-10
400 kcmil TLK240-10
600 kcmil TLK400-12
750 kcmil TLK400-12
9 AWG TLK10-8
5 AWG TLK25-8
2 AWG TLK35-8
2/0 AWG TLK70-8
3/0 AWG TLK95-10
4/0 AWG TLK120-10
250 kcmil TLK150-10
300 kcmil TLK185-10
400 kcmil TLK240-10
600 kcmil TLK400-12
750 kcmil TLK400-12
9 AWG TLK10-8
5 AWG TLK25-8
Spezifikationen
Schraubentyp Anzugsmoment
(Nm)
M8×25 12,0–15,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M8×25 12,0–15,0
M8×25 12,0–15,0
M8×25 12,0–15,0
M8×25 12,0–15,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M8×25 12,0–15,0
M8×25 12,0–15,0
M8×25 12,0–15,0
M8×25 12,0–15,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
M10×35 30,0–50,0
Mutter M8 12,0–15,0
Mutter M8 12,0–15,0
AQ363633621020de-000201 / 172F8675
