IFM Electronic ecomat 100 CR2530 Original-Programmierhandbuch Seite 271

ifm Programmierhandbuch ecomatmobile
Anhang
Index S-Idx Parameter name
0xC Configuration IN11
0x2000 0xD Configuration IN12
0xE Configuration IN13
0xF Configuration IN14
0x10 Configuration IN15
0x2000 0x11 Configuration OUT00
0x12 Configuration OUT01
0x2000 0x13 Configuration OUT02
0x14 Configuration OUT03
0x15 Configuration OUT04
SmartController (CR2530, CR2532) Laufzeitsystem V03.02
Data type Default
rw USINT
rw USINT
rw USINT
rw USINT
rw USINT
rw USINT
rw USINT
rw USINT
rw USINT
rw USINT
271
Integriertes E/A-Modul: Beschreibung
Details
10 0 = 0x00 off
10 = 0x0A binary plus switched
11 = 0x0B binary plus switched with diagnosis
1 0 = 0x00 off
1 = 0x01 binary plus switched, digitally monitored
14 = 0x0E frequency 0...30 000 Hz
19 = 0x13 period duration
20 = 0x14 period duration as ratio 0...1 000 ‰
21 = 0x15 counting up
22 = 0x16 counting down
23 = 0x17 incremental encoder
1 0 = 0x00 off
1 = 0x01 binary plus switched, digitally monitored
14 = 0x0E frequency 0...30 000 Hz
19 = 0x13 period duration
20 = 0x14 period duration as ratio 0...1 000 ‰
21 = 0x15 counting up
22 = 0x16 counting down
23 = 0x17 incremental encoder
1 0 = 0x00 off
1 = 0x01 binary plus switched, digitally monitored
14 = 0x0E frequency 0...30 000 Hz
19 = 0x13 period duration
20 = 0x14 period duration as ratio 0...1 000 ‰
21 = 0x15 counting up
22 = 0x16 counting down
23 = 0x17 incremental encoder
1 0 = 0x00 off
1 = 0x01 binary plus switched, digitally monitored
14 = 0x0E frequency 0...30 000 Hz
19 = 0x13 period duration
20 = 0x14 period duration as ratio 0...1 000 ‰
21 = 0x15 counting up
22 = 0x16 counting down
23 = 0x17 incremental encoder
2 0 = 0x00 off
2 = 0x02 binary plus switched
4 = 0x04 PWM output
5 = 0x05 current control
15 = 0x0F binary plus switched with diagnosis
16 = 0x10 binary plus switched with diagnosis + protection
2 0 = 0x00 off
2 = 0x02 binary plus switched
4 = 0x04 PWM output
5 = 0x05 current control
15 = 0x0F binary plus switched with diagnosis
16 = 0x10 binary plus switched with diagnosis + protection
2 0 = 0x00 off
2 = 0x02 binary plus switched
4 = 0x04 PWM output
15 = 0x0F binary plus switched with diagnosis
16 = 0x10 binary plus switched with diagnosis + protection
2 0 = 0x00 off
2 = 0x02 binary plus switched
4 = 0x04 PWM output
15 = 0x0F binary plus switched with diagnosis
16 = 0x10 binary plus switched with diagnosis + protection
2 0 = 0x00 off
2 = 0x02 binary plus switched
4 = 0x04 PWM output
15 = 0x0F binary plus switched with diagnosis
16 = 0x10 binary plus switched with diagnosis + protection
2015-03-26
Input IN11
Input IN12
Input IN13
Input IN14
Input IN15
Input OUT00
Input OUT01
Input OUT02
Input OUT03
Input OUT04
