Guidance and Manufacturer's Declaration Regarding Electromagnetic Immunity – Non-life Supporting
The Model 82-6634 ICP EXPRESS Monitor is intended for use in the electromagnetic environment specified below. The customer or user of the
Model 82-6634 ICP EXPRESS Monitor should ensure that it is used in such an environment.
Immunity Test
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
Reference Table 204 EN 60601-1-2
Recommended Separation Distances Between Portable and Mobile RF Communications Equipment and the Model 82-6634
The Model 82-6634 ICP EXPRESS Monitor is intended for use in the electromagnetic environment in which radiated disturbances are controlled. The
customer or user of the Model 82-6634 ICP EXPRESS Monitor can help prevent electromagnetic interference by maintaining a minimum distance
between portable and mobile RF Communications Equipment and the Model 82-6634 ICP EXPRESS Monitor as recommended below, according
to the maximum output power of the communications equipment.
Maximum
Output Power
(Watts)
0.01
0.1
1
10
100
Reference Table 206 EN 60601-1-2
5:05 PM Page 12
IEC 60601 Test Level Compliance Level
3 Vrms from V1 = 3 Vrms
150 kHz to 80 MHz
3 V/m E1 = 3 V/m
80 MHz to 2.5 GHz
ICP EXPRESS Monitor (Equipment and Systems that are NOT Life-Supporting)
Recommended Separation Distances for the Model 82-6634 ICP EXPRESS Monitor
150 kHz to 80 MHz
d = 1.1667
0.11667
0.36894
1.1667
3.6894
11.667
Where P is the maximum output power rating in watts and d is the recommended separation distance in meters.
Table 3
Electromagnetic Environment Guidance
Portable and mobile communications equipment should be
separated from the Model 82-6634 ICP EXPRESS Monitor
by no less than the recommended separation distances
calculated/listed below:
d = [3.5/V1]
d = [3.5/E1]
80–800 MHz
d = [7/E1]
800 MHz – 2.5 GHz
Where P is the maximum output power rating in watts and
d is the recommended separation distance in meters.
Field strength from fixed transmitters as determined by
an electromagnetic site survey, should be less than the
compliance levels (V1 and E1).
Interference may occur in the vicinity of equipment
containing a transmitter.
Table 4
80 MHz to 800 MHz
d = 1.1667
0.11667
0.36894
1.1667
3.6894
11.667
12
800 MHz to 2.5 GHz
d = 2.3333
0.23333
0.73785
2.3333
7.3785
23.333
