4 Identification

4.1 Product description and type
designation
ULISSE PLUS NETCAM is a powerful Full-IP PTZ for
outdoor IP video surveillance, which can manage
modern IP SD, HD and Megapixel cameras, with
integration into a network system.
This model can contain cameras with medium-sized
lenses, enabling dynamic and non-stop surveillance
of large outdoor areas at 360° degrees.
A special feature of ULISSE PLUS NETCAM is the
ability to easily control, via the network, all the
camera's pan & tilt functions, including wiper, preset
and set-up, using the most common VMS on the
market. It is possible to use any ONVIF compatible
Profile S camera, or proprietary protocol on RS-485,
whilst the entire management of the system only
requires an IP address.
The unit is equipped with a wiper for removing
rain and dust from the front glass; there is a wide
selection of jerry cans with washer pump, different
capacities and heads.
To ensure detailed images even during the night
hours, versions are available with LED illuminators,
with infrared light or white light.
The accurate top-mount construction ensures vision
beyond the horizon and the continuous rotation on
the horizontal axis, combining high speed to absolute
tracking accuracy, both in manual mode and in patrol
mode.
The unit is equipped with optical sensors which
ensure the accurate control of the position in any
condition of use.
10

4.2 Product markings

Pan & tilt devices have a label complying
with CE markings.
Fig. 1
The label shows:
• Model identification code (Extended 3/9 bar code).
• Power supply (Volt).
• Frequency (Hertz).
• Current consumption (Amps).
• Weatherproof standard (IP).
• Serial number.

4.2.1 Checking the markings

Before proceeding further with installation, make
sure the material supplied corresponds to the order
specification by examining the marking labels.
Never, under any circumstances, make any changes
or connections that are not shown in this handbook.
Improper use of the appliance can cause serious
hazards, risking the safety of personnel and of the
installation.
MNVCUPTPLUS3_1511_EN
