17 Technical data

17.1 General

Constructed from aluminium and tecnopolymer
Epoxypolyester powder painting, RAL9002 colour
Top mount (OTT)
Transmission through toothed belt
Slip-ring
Electronic limit switches
Simplified installation thanks to the connector and
easy replacement on-site
Zero backlash
Encoder for absolute positioning
Integrated wiper
Configuration of telemetry protocol parameters
through dip-switch for RS485
MNVCUPTPLUS3_1511_EN

17.2 Mechanical

Cable glands: 3xM16
Horizontal rotation: continuous
Vertical rotation: +90° to -40°
Horizontal speed (variable): from 0.02°/s up to 100°/s
(from 0.02°/s up to 40°/s, with LED illuminators)
Tilt speed (variable): from 0.02°/s up to 50°/s (from
0.02°/s up to 30°/s,with LED illuminators)
Internal usable area: See drawings
Enclosure glass window (WxH): 124x112mm
(4.9x4.4in)
Preset accuracy: 0.02°
Unit weight: 16.8kg (37lb) (17.8kg (39.2lb), with LED
illuminators bracket)
