17.3 Electrical

Suitable for use with network cameras
Power supply/Current consumption:
• 230Vac, 0.4A, 50/60Hz
• 24Vac, 4A (8A with LED illuminators), 50/60Hz
• 120Vac, 0.8A, 50/60Hz
Power consumption:
• 100W
• 150-190W max with LED illuminators in 24Vac
• 28.5W, P&T stopped, heating switched off
Camera power supply: 12Vdc (800mA)
4 self-powered alarm inputs
2 dry contacts: 30Vdc max o30Vac, @ 1A

17.4 Communications

Ethernet connection: IEEE 802.3 100Base-Tx

17.5 Protocols

ONVIF, S profile
46

17.6 Environment

Indoor/Outdoor
Operating temperature
• With heater: -20°C (-4°F)/+60°C (140°F)
• With reinforced heater: -30°C (-22°F )/+60°C
(140°F)
Surge immunity: up to 2kV line to line, up to 4kV line
to earth (Class 4)

17.7 Certifications

Electrical safety (CE): EN60950-1, IEC60950-1
Electromagnetic compatibility (CE): EN50130-4,
EN610000-6-4, EN55022 (Class A), FCC Part 15 (Class
A)
Outdoor installation (CE): EN60950-22, IEC60950-22
Photobiological safety (CE): EN62471 LED
illuminators)
IP protection degree: EN60529, IP66
Salty fog resistance: EN50130-5, EN60068-2-52
UL certification: cULus Listed (TYPE 4X)
EAC certification
