11 Accessories

For further details on configuration and
use, refer to the relative manual.

11.1 Washer

The P&T can be equipped with an external pump that
supplies water for the glass to be cleaned.
When a control is provided, the Pan & Tilt is
positioned with the window in front of the nozzle. (
10.1.3 User Controls, page 33). The pump and wiper
are activated for a set period of time. At the end of
the operation the P&T returns to its initial position.
Fig. 76
40

11.1.1 Washing system connection

CAUTION! TNV-1 installation type. The
installation is type TNV-1, do not connect it
to SELV circuits.
CAUTION! In order to reduce the risk of fire,
only use UL Listed or CSA certified cables
sizes greater than or equal to 0.13mm² (26
AWG).
All signal cables must be grouped together
by means of a strap.
WASHING SYSTEM CONNECTION
Terminals
O1-C1
Tab. 14
Fig. 77
Description
Clean contact to activate the
washing system.
O1 C1
