Wilo Control EC-L Einbau- Und Betriebsanleitung Seite 82

en
Fig. 41: Menu 5.43
Fig. 42: Menu 5.44
Fig. 43: Menu 5.50
Fig. 44: Menu 5.51
Fig. 45: Menu 5.57
Fig. 46: Menu 5.58
82
All manuals and user guides at all-guides.com
Commissioning
Menu no.
Description
Value range
Factory setting
Menu no.
Description
Value range
Factory setting
Menu no.
Description
Value range
Factory setting
Explanation
Menu no.
Description
Value range
Factory setting
Menu no.
Description
Value range
Factory setting
Explanation
Menu no.
Description
Value range
Factory setting
Explanation
5.43
"Pump kick running time"
0 ... 60 s
5 s
5.44
Activation delay after power failure
0 ... 180 s
3 s
5.50
Dry-running level (drain)/ min. water level (fill)
0 ... 12.5 m
0.15 m
If the level is monitored with a separate float switch, deac-
tivate the level sensor: Enter the value "0.00 m".
5.51
High water level
0 ... 12.5 m
0.46 m
5.57
Max. running time per pump
0 ... 60 min
0 min
Maximum permissible running time of a pump. Once the
time has been exceeded, the system switches to the next
pump. After three change cycles, the collective fault signal
(SSM) is activated.
The setting "0 min" switches the running time monitoring
off.
5.58
Collective run signal (SBM) function
on, run
run
"on": Switchgear ready for operation
"Run": At least one pump is running.
WILO SE 2018-12
